DBA 4000 Series XS Drilled & Slotted Brake Rotors

*Black High Temperature Coating

DBA (Disc Brakes Australia) 4000 Rotors are a direct replacement single-piece brake rotor, designed for drivers seeking upgraded performance braking above and beyond standard OE levels. Cast from XG-150 high carbon alloyed iron and undergoing Thermal Stability Profiling (TSP), DBAs metallurgy is able to handle the increased stress and heat generated under intense braking applications, time and time again. Featuring DBAs patented Kangaroo Paw ventilation that implements a series of 144 diamond and teardrop patterned pillars, DBA achieves up to a 30% increase in surface area and 20% improvement in cooling efficiency (as compared to a traditional straight vane design)

Expert Opinion

DBA 4000 XS Rotors are one of the highest quality cross-drilled rotors on the market today. Not as durable as the T3 version because of the cross-drilled holes. The XS version fits the bill when you want a high quality rotor and the look of a cross-drilling. The XS version is not recommended for motorsports usage, but is more than capable for high performance street use. On average, these rotors will last mush longer than most other rotors on the market.

DBA 4000 Series XS Rotor Features

• XG-150 High Carbon Alloyed Iron
• TSP (Thermal Stability Profiling)
• Thermo-graphic paint markings (THGP)
• Direct replacement suitability
• Moisture proof corrosion protection packaging

Thermal Stability Profiling

Thermal Stability Profiling (TSP), is a DBA proprietary process, developed for use with all 4000 and 5000 Series high carbon disc rotors. Under the TSP process, XG-150 grey iron is subjected to prolonged heat cycles under strictly controlled conditions, to relieve any internal stresses sustained from the manufacturing processes. This ensures maximum thermal stability and reduced metal fatigue in extremely high demanding applications. DBAs comprehensive materials testing both on the race track and in computer simulations has enabled the development of this temperature cycling process to optimize the disc rotor material prior to fitting on the vehicle.

• Improved fatigue resistance to minimize surface cracking
• Reduced rotor fatigue during prolonged heavy braking
• Quick replacement, minimal “bedding-in” of rotors

Thermal Graphic Heat Paint

DBAs patented Thermo-Graphic Heat Paint (TGHP) markings are a standard feature on all DBA 4000 and 5000 Series disc rotors. The TGHP paint stripes of Green, Orange and Red will change color once your DBA rotor reaches predetermined critical temperature thresholds. Drivers can monitor peak rotor temperatures to better understand the effects of their driving style and make informed choices in pad selection or whether their driving style is best for the application. TGHP color coding is incorporated with DBAs range of Performance Pads, with the Performance Pads color coded to the heat thresholds. When your TGHP stripes change color, you should ensure you have the right DBA pads to match.

WARNING

This product can expose you to Silica, crystalline (airborne particles of respirable size), which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov

[instruction]

DBA Rotor Cleaning

Cleaning a disc rotor correctly will often eliminate any issues with squeal, runout (DTV) and pad contamination. Most disc rotors have a protective coating applied post production to avoid any corrosion during storage. Its a simple process that can be done in less than a minute.

• Use a suitable brake parts cleaner. – Please Note: Carburetor cleaner and brake cleaner products are not the same. Carb cleaner is intended to leave a lubricating residue whereas brake clean will leave a dry surface.
• Apply the brake part cleaner to a clean cloth or paper towel. – Applying directly onto the disc rotor can damage any paint coating intended to protect the rotor from corrosion.
• Wipe in a circular motion around the friction ring surface.

[/instruction][warranty]
